Epoxy Dispensing Machine

1.1 Production Capacity: depends on the battery cover model

1.2 Dimension (LWH): 1380 mm × 1100 mm × 1800 mm

1.3 Applicable Epoxy/Glue: epoxy for cover dispensing (battery cover length < 560 mm, battery cover width < 300 mm)

1.4 Proportion: 100:10 ~ 100:100 ± 3%, adjustable

1.5 Working Range: 600 (X) * 600 (Y) * 100 (Z) mm

1.6 Max. speed: 400 mm/s

1.7 Proportion Accuracy: ± 3%

1.8 Glue Output Accuracy: ± 0.1 g

1.9 Glue Output Speed: 0.1 g/s ~ 15 g/s

1.10 Metering method: servo motor + gear pump

1.11 Transmission method: servo motor

1.12 Power: AC 220V, 50HZ, 0.5 – 1.5 KW

1.13 Working temperature: Moisture 20 ~ 90%, Temperature 0 ~ 40℃
