1. Features

◆ Entirely oxygen free drying so that there will not be any oxidation on the plate during drying process allowing an excellent function of engine starting.

· Only 20% of manpower is required to operate our advanced drying method compare to traditional drying method, therefore the overall efficiency is enhanced greatly.

◆ Easy operation system, special training is not required.

◆ Entire inert gas oven is made from stainless steel, including main circulation fan, capable of 24 hours, 7 days a week operation, it is durable, efficient, and reliable.

2. Performance

◆ Drying capacity per batch load is approximately 3000~4000 panel plates (60 min), Drying Time: 90 min per batch; Drying Temperature: 120℃.

◆ Simple operation: One time operation can be achieved from retrieval of plates from the formation tank to drying.

· Combustion system: Adopt first class parts from US North American factory to ensure the most precise combustion and stable pilot fire.

◆ Water cooling system: Adopt highly efficient circulating cooling system with large dehumidifying net to ensure the best drying performance in the shortest amount of time.

3. Plate Characteristics after Drying

◆ Water content is less than 0.1%.

◆ PbO increase rate is less than 1%.

◆ PbO content is less than 3%.

◆ After drying plates in the inert gas oven, the lead content is extremely high and therefore it gives maintenance-free battery or dry charged battery supreme product performance.

4. Capable of drying positive plates

◆ For positive plates, it provides different factory setting for low temperature drying environment to ensure the material on the plate won't be changed or deactivated. It greatly enhances the dry charged ability and its lifetime.
